2.6.16. KSB

2.6.16.1. Introduction

Balcony of King College Strand building in the City of Westminster, London. Same building as KSS, KSSW and KSS45W.

2.6.16.2. Site metadata

Site ID	KSB
Full Name	Kings College London (Strand Campus) Strand Building Balcony
Network	LUMA
Longitude	-0.116351	degrees
Latitude	51.512104	degrees
Start date	2013-03-04	UTC
End date	2015-09-18	UTC
Displacement height	19.0	m
City	London

2.6.16.3. Deployments at site

Table 2.85 All site deployments

Deployment ID	Instrument ID	Instrument serial	Type	Deployment name	Start date	End date
					UTC	UTC
53	CSAT3	0192-2	ec	Eddy cov	2015-09-17	2016-02-18
53	LI7500A	75H-1973	ec	Eddy cov	2015-09-17	2016-02-18
340	GILL121R03	307	ec	Eddy cov	2013-03-04	2015-09-17

Table 2.86 Position of deployments

Deployment ID	Height	Yaw	Pitch	Roll
	m asl	degrees	degrees	degrees
53	34.42	246.0
53	34.42	243.0
340	34.42	330.0

2.6.16.4. Photos

Fig. 2.44 GILL121R03 05-07-2015.

2.6.16.5. Data acquisition

Data can be requested from Prof. Sue Grimmond (c.s.grimmond@reading.ac.uk).

2.6.16.6. Data availability

Double click on legend to isolate instruments.

2.6.16.7. References

1. Bjorkeren, A. B., Grimmond, C. S. B., Kotthaus, S. and Malamud, B. D. (2015) CO2 emission estimation in the urban environment: measurement of the CO2 storage term. Atmospheric Environment, 122. pp. 775-790. ISSN 1352-2310 doi: https://doi.org/10.1016/j.atmosenv.2015.10.012

2.6.16.8. Acknowledgements

We thank King College London Directorate of Estates Facilities for site access.
