2.6.5. BGH

2.6.5.1. Introduction

Gilbert house in the Barbican estate in the City of London. A Davis weather station has been deployed here.

2.6.5.2. Site metadata

Site ID	BGH
Full Name	Barbican Gilbert House
Network	LUMA
Longitude	-0.093295	degrees
Latitude	51.518777	degrees
Start date	2014-01-18	UTC
End date	2018-10-31	UTC
Displacement height	-999.0	m
City	London

2.6.5.3. Deployments at site

Table 2.61 All site deployments

Deployment ID	Instrument ID	Instrument serial	Type	Deployment name	Start date	End date
					UTC	UTC
3	DAVIS	AK130521017	single	Davis weather station	2014-01-18	2018-10-31

Table 2.62 Position of deployments

Deployment ID	Height	Yaw	Pitch	Roll
	m asl	degrees	degrees	degrees
3	49.0	22.0	0.0	0.0

2.6.5.4. Photos

Fig. 2.16 DAVIS station looking towards the South East 02-02-2016.

2.6.5.5. Data acquisition

Data can be requested from Prof. Sue Grimmond (c.s.grimmond@reading.ac.uk).

2.6.5.6. Data availability

Double click on legend to isolate instruments.

2.6.5.7. References

1. Warren, E., Charlton-Perez, C., Kotthaus, S., Lean, H., Ballard, S., Hopkin, E. and Grimmond, S. (2018) Evaluation of forward-modelled attenuated backscatter using an urban ceilometer network in London under clear-sky conditions. Atmospheric Environment, 191. pp. 532-547. ISSN 1352-2310 doi: https://doi.org/10.1016/j.atmosenv.2018.04.045

2.6.5.8. Acknowledgements

We thank Barbican for site access.
